Overview
The packing machine—born from relentless research and development,and strictly in compliance global quality standards.All kinds of types of complete, professional packaging solutions, ready to meet every need you have.
Bottom paper feed -3 servo
Stable operation, low noise and low failure rate;
The transmission system is simple, making operation more reliable and maintenance more convenient;
The whole machine has a compact structure, is sturdy, rationally designed and simple;
Supports multi-language touch screen display, with intuitive and simple operation;
FEATURES
The human-machine interface makes parameter setting convenient and fast;
The self-diagnosis function for faults makes the fault display clear at a glance;
The process from metering, filling and bag making, date printing to product output is fully automatic and completed in one go;
Controlled by software, it is convenient for functional adjustment and technological upgrading, and will never fall behind.
BENEFITS
Stable operation, low noise and low failure rate;
The transmission system is simple, making operation more reliable and maintenance more convenient;
The whole machine has a compact structure, is sturdy, rationally designed and simple;
Supports multi-language touch screen display, with intuitive and simple operation;
SPECIFICATIONS
| Model型号 | TCZB-250X 3 Servo Motor | TCZB-350X 3 Servo Motor | ||
| Film width膜宽 | Max.250mm | Max.350mm | ||
| Film width Range 膜宽范围（少于100mm膜宽建议配固定成型器） | 80-114mm/ 114-180mm/ 140-250mm | 140-250mm/ 250-320mm/ 320-350mm | ||
| Bag width(only can choose one range) 袋子宽度范围-只能选其一 | 25-42mm/ 42-75mm/ 55-110mm | 55-110mm/110-145mm/145-160mm | ||
| Bag Length((只有最短袋子长度， 最长袋子长度没限制） | 低刀35高 Min.65 | 高刀45高 Min.90 | 低刀35高 Min.65 | 高刀45高 Min.90 |
| Product Height 产品高度 | Max.40mm | Max.50mm | Max.40mm | Max.50mm |
| Speed 速度 | 40-200bags/min | 40-200bags/min | ||
| Weight 重量 | 400kg | 430kg | ||
| Power 电压 | 220V,50/60HZ, Single Phase | 220V,50/60HZ, Single Phase | ||
| Dimension 机器尺寸 | (L)3920*(W)670*(H)1320mm | (L)4020*(W)720*(H)1320mm 双排气：4390*740*1375mm | ||
| Film roll diameter 卷膜最大外径 | Max.320mm | Max.320mm | ||
| Product Height 产品高度 | 132 Ultra-high Knife (knife height 55) – Single-knife bag-making length 150-380mm, product height 60mm 132 Ultra-high Knife (knife height 55) – Double-knife bag-making length to be determined, product height 60mm 132超高刀（刀高度55）-单刀制袋长度150-380mm，产品高度60mm 132超高刀（刀高度55）-双刀制袋长度待定，产品高度60mm | |||
