Overview
Integrating automation, informatization, intelligence and laser “intelligent” manufacturing,
we provide a full range of laser cutting equipment. Comprehensively layout laser intelligent equipment and provide overall solutions for the construction of automated production lines and smart factories.
Tube laser cutting
.High cost performance, exceeding expectations;
.Cut materials along with the hole,prevent slipping and injury, and avoid getting off;
.Intelligent and efficient, with outstanding quality;
.The software interface is simple and comprehensiv;
.For the cutting of productsIt displays 3D images and uses device informationIt’s clear at a glance;
.Comprehensive process database.
FEATURES
.High cost performance, exceeding expectations;
.Cut materials along with the hole,prevent slipping and injury, and avoid getting off;
.Intelligent and efficient, with outstanding quality;
.The software interface is simple and comprehensiv;
.For the cutting of productsIt displays 3D images and uses device informationIt’s clear at a glance;
.Comprehensive process database.
BENEFITS
.Both plates and pipes can be processed, making it a multifunctional machine
The product types are rich and diverse, integrating numerical control technology and laser cutting integrates cutting and precise cutting. Mainly used for carbon steelCutting of metal pipes such as pipes, stainless steel pipes, aluminum alloy pipes,etc
.The machine tool has a stable structure and anti-vibration ensures the processing quality.
.A powerful control system
Professional control system for laser pipe cutting machinesBased on the German control system, the needleSecondary development of the laser pipe processing industry.
SPECIFICATIONS
| Model | TUBE 6015 | TP6535 Plus | TP6535 Pro | LT 6535 |
| The King of small pipe processing | The King of cost performance | The King of pipe processing for external use | The king of high speed, high precision and high efficiency | |
| Numerical control system数控系统 | FARLEY-A | FARLEY-B | FARLEY-B | SIEMENS |
| Servo motor伺服电机 | 台达Delta | 安川Yaskawa | 安川Yaskawa | SIEMENS |
| Processing pipe diameter range 加工管径范围 | φ20-219mm | φ20-219mm | φ20-220mm | φ20- 220mm/250mm |
| Feeding form 上料形式 | Manual/semi-automatic | Manual/semi-automatic | Manual/semi-automatic/fully automatic Feeding | Manual/semi-automatic/fully automatic Feeding |
| 加工材质 Processing materials | Carbon steel, stainless steel, aluminum alloy | Carbon steel, stainless steel, aluminum alloy | Carbon steel, stainless steel, aluminum alloy | Carbon steel, stainless steel, aluminum alloy |
| Maximum upper limit of pipe Material length 管材最大上料长度 | 6100mm | 6300mm | 6500mm | 6500mm |
| The maximum cutting length of the pipe 管材最大下料长度 | 1500mm | 3000mm | 3500mm | 3500mm |
| Maximum single tube weight 最大单管重量 | 150Kg | 150Kg | 250KG | 250KG |
| laser power 激光功率 | 1000-3000W | 1000-3000W | 1000-4000W | 1000-6000W |
| cutting head 切割头 | Raytools | Raytools | Raytools | Precitec |
| Machine tool volume 机床体积 | 10×2.5×2.6m | 12×2.5×2.9m | 12×5×2.6m | 15×5.5×2.6m |
